ASI QUINT 100-240/2.4 EFD
Climatic Data (Continued)
Shock (in all space directions) according to
IEC 60068-2-27
Degree of pollution according to EN 50178
Climatic category according to EN 60721
30g
2
3K3
Conformance With EMC Directive 89/336/EEC and Low Voltage Directive 73/23/EEC
Noise Immunity Test According to EN 61000-6-2 1
Electrostatic discharge (ESD)
EN 61000-4-2
Criterion B 2 Housing:
Level 4
Contact discharge: 8 kV
Air discharge:
15 kV
Electromagnetic HF field
EN 61000-4-3
Criterion A 3 Housing:
Frequency/field
strength:
Level 3
80 MHz - 1000 MHz/
1.4 GHz - 2.0G Hz/
10 V/m
Fast transients (burst)
EN 61000-4-4
Criterion B 2 Input:
Output:
Signal:
4 kV (Level 4) 4
2 kV (Level 3) 4
1 kV (Level 2) 4
Surge current loads (surge)
EN 61000-4-5
Criterion
B 2
Input:
4 kV 4 /2 kV 5 (Level 4)
Output:
Signal:
0.5 kV 4 /0.5 kV 5 (Level 1)
1 kV 4 (Level 2)
Conducted interference
EN 61000-4-6
Criterion A 3 Input/Output/
(Level 3) 4
Signal:
Frequency/U 0 :
0.15 MHz - 80 MHz/10 V
Voltage dips
EN 61000-4-11 Criterion B 2 Input: See mains
> 20 ms
buffering
Noise Emission Test According to EN 61000-6-3
Radio interference emission
Radio interference voltage
EN 55011
EN 55022 6
EN 55011
EN 55022 6
Class B 7
Class B 7
1
EN 61000 corresponds to IEC 61000
2
3
4
5
Criterion B:
Criterion A:
Asymmetrical:
Symmetrical:
Temporary adverse effects on the operating characteristics, which the device corrects automatically.
Normal operating characteristics within the specified limits.
Cable to ground
Cable to cable
6
EN 55011 corresponds to CISPR11, EN 55022 corresponds to CISPR22/EN 61000 corresponds to IEC 61000
4
7
Class B:
Industrial and domestic applications
102045_01_en
